Slurm

What is Slurm?

A computational cluster is made up of multiple resources which can be exploited to run a big number of tasks at the same time. In order to achieve this goal, you need to use a software called job scheduler, in our case is Slurm, an open source cluster management and job scheduler system.

The job scheduler allows users to specify computational tasks, known as jobs, that are going to be automatically distributed across the available and most suitable resources (see image below). A job can be any computational task as long as it respects specific restrictions, for example it could be a specific section of your preprocessing analysis, or the whole analysis of a single subject.

How to think about jobs

If you are using Cecile, you most likely need to run multiple similar jobs at the same time, the key to achieve this goal is to code your analysis with the objective of making it parallelizable:

Create scripts that process only one dataset (e.g. one participant) at a time. In this way one job is going to correspond to one task, for example the preprocessing of a single subject dataset.
Chunk your analysis in steps. In this way, especially if you are new to slurm, you have more control on your analysis, your outcomes and it reduces the duration of your jobs.

How to run a job in Slurm

There are different types of jobs in slurm (e.g. single jobs, interactive jobs etc.), but before talking about the specific jobs there are a few things you need to take care of:

Make sure that the code you want to use for your jobs works properly. Especially at the beginning it might difficult to identify the reason why a job is failing, thus by making sure that your scripts run as intended you can restrict your error space.
Make sure your scripts (e.g. in bash) are executable.
Making a file executable

Add the so called shebang on top of your bash script, it will tell the system to use the bash interpreter to run the code:
```
#!/bin/bash
```
Once you have done that, run the following command to make your script exacutable:
```
chmod +x <script.sh>
```
For python use the following shebang in the first line of your script:
```
#!/usr/bin/env python3
```
And then make it exacutable from the command line:
```
chmod +x <script.py>
```
Create a folder called slurm-logs (or you can give it another meaningful name), in the same directory as the scripts are or in the scratch of your project. Slurm will use it to dump the logs reporting error files and printed outputs.
Activate the software stack environment or load the modules that you need for your code.
This needs to be done inside the script used to run your slurm jobs (see in the script examples).

In order to specify a job in Slurm, you need to make a few decisions and provide a few essential information to the system beforehand.

Ask yourself the following questions before setting up your job

How long does your job need to run?
How many CPUs does your job need?
How much memory does your job need?
Does your job require any special hardware feature?

The following parameters are not all mandatory, but we strongly recommend to define all of them. If you do not define them properly your job might not run as expected, might stop or even fail and you might involuntarily take resources away from other users.

Here it is how you turn the previous questions in parameters for slurm script.

Setting Slurm parameters
#!/bin/sh

#SBATCH --job-name=my_job
#SBATCH --mail-user=<name.lastname>@ovgu.de
#SBATCH --mail-type=BEGIN,END,FAIL
#SBATCH --cpus-per-task=1
#SBATCH --nodes=1
#SBATCH --mem-per-cpu=1g
#SBATCH --time=01:00:00
#SBATCH --output=slurm-logs/%x-%A-%a.out
#SBATCH --error=slurm-logs/%x-%A-%a.err

# is not a comment in SLURM

Keep in mind that for your slurm script the # before SBATCH is not interpreted as a shell comment

#SBATCH --job-name=my_job: the name you provide for your job
#SBATCH --mail-user=<name.lastname>@ovgu.de: your email address, in case you want to receive a job feedback by email.
#SBATCH --mail-type=BEGIN,END,FAIL: get an email at the beginning of a job, end of a job and when a job fails, respectively.
#SBATCH --cpus-per-task=1: number of CPUs you request for a task
#SBATCH --nodes=1: number of requested nodes, keep it to 1, it is fine for our type of analyses.
#SBATCH --mem-per-cpu=1g: amount of memory you request per cpu.
#SBATCH --time=01:00:00: maximum duration you assign to a job (D-HH:MM:SS, for example --time=00:01:00 is a one minute job).
#SBATCH --output=slurm-logs/%x-%A-%a.out: here you specify where job printed output should be saved, specifically in the folder slurm-logs.
#SBATCH --error=slurm-logs/%x-%A-%a.err: here you specify where job related errors should be saved, again in the folder slurm-logs.

Instead of --mem-per-cpu you could also use --mem, the latter specifies the amount of RAM you request in a node.

Be aware of memory and time

If your job exceeds the requested memory, your job will be aborted.
If your job exceeds the requested time, your job will be aborted.

Job ID

The job ID is the identification number relative to a job that can be used to acquire information about your job, or to abort your job. It might look something like this 217379_5, where the prefix number before the underscore indicates the general job session, while the number after the underscore indicates the specific number of a job. You might have multiple jobs sharing the session number.

Types of Slurm jobs

Single jobArray jobInteractive job

It allowes to run only a single job.

Use case: It is ideal when you want to test a specific analysis and test it on one subject, or when you need to run just one analysis like a group statistical analysis.

The following is a prototypical slurm script. You can use the name and the extension you prefer, we recommend to use <filename>.slurm

Slurm single job

#!/bin/sh

#SBATCH --job-name=my_job
#SBATCH --cpus-per-task=1
#SBATCH --nodes=1
#SBATCH --mem-per-cpu=1g
#SBATCH --time=01:00:00
#SBATCH --output=slurm-logs/%x-%A-%a.out
#SBATCH --error=slurm-logs/%x-%A-%a.err

./my_script.sh

To run a job you use the following command:

sbatch <filename>.slurm

You can now run squeue to see the status of your job, let's understand the squeue output:

A running job

            JOBID PARTITION     NAME     USER ST       TIME  NODES NODELIST(REASON)
        217379_0       all fmriprep    user   R       1:10      1 compute05

A pending job

            JOBID PARTITION     NAME     USER ST       TIME  NODES NODELIST(REASON)
        217379_0       all fmriprep    user  PD       1:10      1 compute05

An idled job

            JOBID PARTITION     NAME     USER ST       TIME  NODES NODELIST(REASON)
        217379_5       all bad_job     user   IDLE    0:00      1 compute05

Let's understand the squeue output:

JOBID: Job indentification number
PARTITION: Name of the partition your jobs are currently using
NAME: Name you gave to your job
USER: Your username
ST: Status of your job
R: A running job
PD: A pending job, it is waiting for resources to be freed
IDLE: An idled job, something might be wrong with your scripts or your in the scirpt for submitting jobs check the error logs
TIME: Time since the job started running
NODES: Number of nodes
NODELIST : Node name

Single job with Matlab

Single job Matlab

#!/bin/bash
#SBATCH --job-name=matlab        # job name, you give it a name you like
#SBATCH --nodes=1                # number of nodes
#SBATCH --ntasks=1               # number of tasks
#SBATCH --cpus-per-task=1        # cpu per task
#SBATCH --mem-per-cpu=1G         # memory per cpu
#SBATCH --time=00:01:00          # max amount of time (D:HH:MM:SS)
#SBATCH --output=slurm-logs/%x-%A-%a.out   # printed output
#SBATCH --error=slurm-logs/%x-%A-%a.err     # errors

## load the software stack
. /software/current/env.sh
## you need to load matlab even if you have loaded already all the modules
## from the software stack
module load matlab

subject=01

## run matlab: you pass just the name of the script without .m in my case matlab_script
matlab -singleCompThread -nodisplay -nosplash -r "matlab_script(${subject})"

Single job with python

Single job Python

#!/bin/bash
#SBATCH --job-name=python        # job name, you give it a name you like
#SBATCH --nodes=1                # number of nodes
#SBATCH --ntasks=1               # number of tasks
#SBATCH --cpus-per-task=1        # cpu per task
#SBATCH --mem-per-cpu=1G         # memory per cpu
#SBATCH --time=00:01:00          # max amount of time (D:HH:MM:SS)
#SBATCH --output=slurm-logs/%x-%A-%a.out   # printed output
#SBATCH --error=slurm-logs/%x-%A-%a.err     # errors

# load the stack and the module you need
. /software/current/env.sh
module load python

subject=01

python -u python_script ${subject}

In case you made your python script executable you can remove the line module load python and call the script as follows: ./python_script ${subject} without prepending python -u

An array job allows you to run multiple jobs in parallel.

Use case: It is ideal when you need to run similar tasks multiple times. For example, the same analysis for many subjects, or you need to test different parameters for the same analysis.

In an array job the crucial parameter is #SBATCH --array which specifies the number of jobs we would like to run simultaneously. You define the array of jobs indicating the range of the jobs, e.g. 1-5 (see highlightened line in the script below)

How to define the --array parameter

Define a range: #SBATCH --array 0-5 from 0 to 5 for 6 total jobs.
Define specific numbers: #SBATCH --array 1, 4, 6, 10 (e.g. they might be specific subject IDs) for 4 total jobs.
Define a range with specific intervals: #SBATCH --array 1-20:2
Define a range and specify the number of parallel jobs: #SBATCH -- array 1-400%100 only 100 jobs are run simultaneously.

#!/bin/sh

#SBATCH --job-name=my_job
#SBATCH --cpus-per-task=1
#SBATCH --nodes=1
#SBATCH --mem-per-cpu=1g
#SBATCH --time=01:00:00
#SBATCH --output=slurm_logs/output-%A-%a.out
#SBATCH --error=slurm_logs/error-%A-%a.err
#SBATCH --array 1-5

Example of an array job

Assume you want to run a specific analysis on 5 subjects in parallel by using a script called my_analysis.sh that requires as a parameter the subject ID. In order to set up a job array you can follow the next steps:

You need to provide to slurm the number of jobs by setting up #SBATCH --array as we have seen above. In this case our range is 0-4, in total 5 jobs as the number of your subjects (remember that the shell interpreter counts starting from 0).
Now you need to pass the subject ID parameter to the script. To do that, you can take advantage of the slurm variable SLURM_ARRAY_TASK_ID which keeps track of the jobs count. This means that for the first job of the array SLURM_ARRAY_TASK_ID will take the value 0, for the second job it will tale the value 1 and so on until the fifth job, for which it will take the value 4. SLURM_ARRAY_TASK_ID can be used as an index to extract the subject ID from the variable subjects.
For the sake of practicality, we can assign SLURM_ARRAY_TASK_ID to the variable idx, which can be used to extract for each job the subject ID, ${subjects[idx]}, and then it can be passed to the script my_analysis.sh.

In other words, for the first job SLURM_ARRAY_TASK_ID is going to be equal to 0 (because your array starts at 0) and so will be idx. Hence, the expression ${subjects[idx]} will extract from the subjects array the first item, namely 01, which is the ID of your first subject. For the second job, SLURM_ARRAY_TASK_ID will be equal to 1 and consequently ${subjects[idx]} will be equal to 02 and so on until the last job.

Not all shells start counting from 0

In this section, we use bash as the reference shell for our examples because this is the default shell in Cecile. bash starts counting arrays from 0, but if you are using other shells like zsh they might start counting from 1. This means that if you use the --array parameter as an index, you must keep in mind where your specific shell interpreter starts counting from. If you use the default bash shell you can just use the examples as they are.

Array job

#!/bin/sh

#SBATCH --job-name=my_job
#SBATCH --cpus-per-task=1
#SBATCH --nodes=1
#SBATCH --mem-per-cpu=1g
#SBATCH --time=01:00:00
#SBATCH --output=slurm_logs/output-%A-%a.out
#SBATCH --error=slurm_logs/error-%A-%a.err
#SBATCH --array 0-4  ## 5 jobs

idx=$((SLURM_ARRAY_TASK_ID))

subjects=(01 02 03 04 05)

./my_analysis.sh ${subjects[idx]}

Now that your array job script is ready you can run it by using the sbatch command as follows:

sbatch my_array_job.slurm

Check whether your jobs are actually running via the command squeue or alternatively with sinfo:

squeue

You should see a similar output:

            JOBID PARTITION     NAME     USER ST       TIME  NODES NODELIST(REASON)
        217379_[6]     all     my_job   user  PD       0:00      1 (Resources)
        217379_0       all     my_job   user   R       1:10      1 compute05
        217379_1       all     my_job   user   R       1:10      1 compute05
        217379_2       all     my_job   user   R       1:10      1 compute05
        217379_3       all     my_job   user   R       1:10      1 compute05
        217379_4       all     my_job   user   R       1:10      1 compute05
        217379_5       all     my_job   user   IDLE    0:00      1 compute05

Let's understand the squeue output:

JOBID: Job indentification number
PARTITION: Name of the partition your jobs are currently using
NAME: Name you gave to your job
USER: Your username
ST: Status of your job
R: A running job
PD: A pending job, it is waiting for resources to be freed
IDLE: An idled job, something might be wrong with your scripts or your in the scirpt for submitting jobs check the error logs
TIME: Time since the job started running
NODES: Number of nodes
NODELIST : Node name

Job array with Matlab

Array job Matlab

#!/bin/bash

#SBATCH --job-name=matlab        # job name, you give it a name you like
#SBATCH --nodes=1                # number of nodes
#SBATCH --ntasks=1               # number of tasks
#SBATCH --cpus-per-task=1        # cpu per task
#SBATCH --mem-per-cpu=1G         # memory per cpu
#SBATCH --time=00:01:00          # max amount of time (D:HH:MM:SS)
#SBATCH --output=slurm_logs/output-%A-%a.out   # printed output
#SBATCH --error=slurm_logs/error-%A-%a.err     # errors
#SBATCH --array 0-4

# load the stack and the module you need
. /software/current/env.sh
module load matlab

idx=$((SLURM_ARRAY_TASK_ID))

subjects=(01 02 03 04 05)

## run matlab: you pass just the name of the script without .m in my case matlab_script
matlab -singleCompThread -nodisplay -nosplash -r "matlab_script(${subjects[idx]})"

Job array with python

Array job Python

#!/bin/bash
#SBATCH --job-name=python        # job name, you give it a name you like
#SBATCH --nodes=1                # number of nodes
#SBATCH --ntasks=1               # number of tasks
#SBATCH --cpus-per-task=1        # cpu per task
#SBATCH --mem-per-cpu=1G         # memory per cpu
#SBATCH --time=00:01:00          # max amount of time (D:HH:MM:SS)
#SBATCH --output=slurm_logs/output-%A-%a.out   # printed output
#SBATCH --error=slurm_logs/error-%A-%a.err     # errors
#SBATCH --array 0-4

# load the stack and the module you need
. /software/current/env.sh
module load python3

idx=$((SLURM_ARRAY_TASK_ID))

subjects=(01 02 03 04 05)

python -u python_script ${subjects[idx]}

In case you made your python code executable you can remove the line module load python and call the script as follows: ./python_script ${subjects[idx]} without prepending python -u

Job array with nested parameters

A typical analysis might require to analyze different subjects with different sessions or different parameters. The following scripts exmplifies a similar case in which each subject needs to be run for three different sessions.

#!/bin/bash

#SBATCH --job-name=multi_param
#SBATCH --output=logs/%x-%A-%a.out
#SBATCH --error=logs/%x-%A-%a.err
#SBATCH --array 0-11

SUBJECTS=(01 02 03 04)
SESSIONS=("ses-01", "ses-02", "ses-03")

SUBJECT_IDX=$((SLURM_ARRAY_TASK_ID % 4))
SESSION_IDX=$((SLURM_ARRAY_TASK_ID % 3))

./my_analysis.sh --sub "sub-${SUBJECTS[SUBJECT_IDX]}" -ses "${SESSIONS[SESSION_IDX]}"

In order to set up a similar script it is necessary to follow a few simple steps:

Set the array range according to the total number of jobs you need to run. In this example we have 4 subjects and 3 different sessions per subject, thus we can set the --array range as 0-11, which amounts to 12 jobs.
Set up one array that defines the subject IDs SUBJECTS and another array that defines the session names SESSIONS.

To assign each session to each subject we can leverage on the modulus operator (take a look at modular arithmetic) to provide the correct index for all the combinations. See in the example below how the modulus allows you to obtain all the index combinations.

Job index  Subject index   Session index      Subject ID      Session ID
           (job index % 4) (job index % 3)
0               0               0               sub-01          ses-01
1               1               1               sub-02          ses-02
2               2               2               sub-03          ses-03
3               3               0               sub-04          ses-01
4               0               1               sub-01          ses-02
5               1               2               sub-02          ses-03
6               2               0               sub-03          ses-01
7               3               1               sub-04          ses-01
8               0               2               sub-01          ses-02
9               1               0               sub-02          ses-01
10              2               1               sub-03          ses-02
11              3               2               sub-04          ses-03

Then extract subject IDs and sessions by using the related indices.

This approach allows you to work interactively inside a given node.

Use case: It is ideal if you need to do some testing, or you just need to run some analyses interactively. Using an interactive job you avoid to work on the head node and take precious resources that are shared among all users.

You can launch an interactive job in the following way:

srun --mem=1G --time=01:00:00 --pty bash

--mem: memory requested (it can be specified in K|G)
--time: time requested for the interactive job
--pty: bash -i allows you use the terminal

Memory and time defaults

In case you do not specify time and memory requirements, by default the maximum amount of time allowed will be 24 hours and the maximum amount of memory will be 4G. If your software requires more time and/or more memory you must specify it.

If you need to use a software with a GUI within an interactive session you should start the job using the following command:

srun --pty --x11 bash

Closing a session

If you close your session on the cluster the interactive job will be ended as well

How to define the amount of resources and time for your jobs

The amount of resources necessary for a job must be decided on a case by case basis, there is no precise rule for choosing them given that too many variables can influence resources and time required. We will give you a few general principles which should work well enough in many instances.

Please do not underestimate this step, your choices influence your own jobs and other users.

One job to rule them all: As a general rule, when your are setting up new slurm jobs, test that everything works as intended by running only one job. It is superfluous to say that this approach saves time for you and time and resources for other users, and importantly it reduces the amount of potential errors.

If you are clueless about your job resource requirements, you could adopt the following approaches:

Trial and error: Set up one job using a very liberal estimate for the resources (e.g. --mem-per-cpu, --time). Once the job is over, you can use one of the following two commands to see the actual resources used and implement them in your future jobs:
```
# job-id is the id of your job
seff <job-id>
```
If you run seff when your job is still ongoing, it will give you an unreliable estimate.
```
sacct -j <job-id> --format=jobid,jobname,reqmem,maxrss,elapsed,timelimit,state
```
Hunt for information: In case you are using a standard tool (e.g. library, toolbox) you might find some indications about minimal resource requirements in the documentation, alternatively you could ask a more expert member of your group or other users (on Mattermost) who might have used a similar tool or pipeline. Both these approaches could be good starting estimates for your jobs.
Run your computation with an interactive job: Set up an interactive job being rather liberal in your choice of resources. Run your computation (e.g. analysis, simulation) and check the resource requirements using the command htop.

Job restrictions and defaults

As for data storage, also jobs need some restrictions in order to guarantee a fair usage for everybody.

Time requested: One job can have a maximum duration of 24 hours. This time duration could be extended by the cluster administrator upon reasonable request. Keep in mind that slurm will stop your job as soon as it exceeds the maximum time duration requested.
Maximum number of array jobs: The maximum number of array jobs you can set are 10000

Slurm basic commands

sinfo # shows you current information about the system

squeue # shows the current jobs status

squeue -U <username> # it provides job status for a given user

sbatch <job_script># launch a job or an array job

scancel <job_ID> # it cancels jobs

scancel -U <username> # all jobs belonging to that user will be cancelled

scontrol show partition compute # allows you to see partitions present and limitations
